Printing Film Making Imagesetter CTF Machine

Name: Printing Film Making Imagesetter CTF Machine
Brand: ECOOGRAPHIX
Price: 1 USD

China Printing Film Making Imagesetter CTF Machine wholesale

Brand Name : ECOOGRAPHIX

Model Number : ECOO2800

Certification : CE

Place of Origin : China

MOQ : 1SET

Payment Terms : L/C, T/T

Delivery Time : 30DAYS

Packaging Details : Standard Export Packing

Price : Negotiable

Supply Ability : 500SETS

Net weight : 3300kg

Warranty : One Year

Max.Window size : (L)400×(W)400

Machine size : (L)4500×(W)1500×(H)1700

Condition : New

Max.Paper size : (L)600×(W)520

Contact Now

Printing Film Making Imagesetter CTF Machine

1. Application

Laser lmagesetter, also known as the Computer to Film(CTF), it is a printing device thatoutputs high-precision, high-resolution images and text on film or photographic paper. lt ischaracterized by high output precision requirements and large output format.EcooGraphix lmagesetters are with full automatic operation during whole process, gridreverting exactly and high precision resetting and so on. Also it is the ideal choice of large platemaking center, news printing, circuit printing and escutcheon trade.

The CTF Imagesetter is used to process the layout graphics and text with RIP (Raster Image Processor), then scan and expose the photosensitive film line by line with a laser, and then develop/fix it to form a negative for printing (i.e. film). The typical process is: computer processing of graphics and text → through interface and RIP driver → laser modulation and scanning → film exposure → development and fixation → the finished film is used for printing and overprinting.

This process is widely used in offset full color printing plate making, silk screen printing, PCB circuit boards and other fields.

Technical Specifications:

Model	Ecoo-2800
Exposure dimensions(mm)	940mm/812mm × 660mm / 610mm / 558mm / 508mm
Scanning precision	1500dpi---4000dpi (optional)
Repeatability Precision	<± 0.010mm
Operation mode	full automatic, on-line operation with 60m roll fifilm and processor, without dark room
Scanning mode	external drum, broad band laser scanning with high speed
Interface condition	All signals are TTL interfacing with computer
Overall dimensions	2580mm×1360mm×1180mm
Production lead time	45 days
Packaging dimension	3 wooden box 1550×1100×1500mm 2020×1200×1350mm 1020x770x920mm
NW	1000KG
GW	1200KG

Printing Film Making Imagesetter CTF Machine
